Automatic Multi-purpose Coating Machine

NEW STAR has launched a new coating machine. With this automatic multi-purpose coating machine, you can apply a protective layer of UV oil varnish to the surface of your paper products, which will help extend their service life. Moreover, it is easy to operate and requires minimal maintenance. Get a UV automatic glazing machine now and make the most of its performance!

The SGUV-T series UV oil coating machine can realize glazing and polishing processes for various types of paper, and can perform coating work with UV oil, water-based oil, and blister varnish oil. After processing by this machine, the surface of printed products will have moisture-proof and waterproof effects.

Specification

Machine details

1.Auto feeder

This machine is equipped with a one-touch acceleration function. After the main machine speeds up, the delivery section, oven, feeder, and metering roller will all automatically adjust according to the machine's running speed.

The metering roller is responsible for controlling the oil coating thickness, and its parameters can be set on the touch screen.

2.Primer coating (with optional air knife device)

As a critical part of the system, the basic head ensures uniform UV application, for enhancing the adhesion between printed ink and UV varnish.

Basic coating head unit has the following features:

3.IR dryer

The working principle of the IR dryer is as follows: When infrared rays reach the coating surface, part of them are reflected or absorbed by the coating surface, and the rest penetrate into the interior of the coating. Among the infrared rays that enter the coating, some pass through the coating, while the remaining part is absorbed by the coating and converted into heat energy, which increases the temperature and accelerates curing.

4. Anilox roller coating head（With air knife）

The oil coating machine refers to the process of coating the glazing paint on the surface of the printed matter and leveling and drying it.

5.Second IR Oven (as point 3)

6.Automatic stacker

Equipped with a fan-cooled pressing mechanism, the automatic paper delivery unit ensures stable operation, which enables the machine to deliver paper flawlessly at high speeds, keeping the sheets neatly arranged.

Optional: Three-roller servo drive

Optional: powder removal (coating)

Optional air conditioning cooling
